Q4SFP-40G-A1 | 40G QSFP+ to 4xSFP+ 1–30m AOC
40G QSFP+ to 4xSFP+ 1–30m AOC with 64 exact SKU options. Confirm the host, port and firmware before quotation.
High-Speed Cables
40G QSFP+ 1–30m AOC | QSFP-40G-A1
Catalog reference: 1m (3ft) Cisco Coding Target QSFP-H40G-AOC1M Compatible 40G AOC QSFP+ to QSFP+ Active Optical Cable
The part numbers on this page identify the requested coding target. Confirm the exact host model, port and firmware for the selected SKU.
40G AOC uses fiber optic technology for data transmission, which can replace copper cables to some extent due to its stability and flexibility, reducing the density and power consumption of cabling. It can also be used for data center and high performance computing network cabling.
Family qsfp-40g-a1-14253Model QSFP-40G-A198 SKU options
Select the exact SKU
Search and select a SKU to update the exact title, description, model and option attributes before sending an RFQ.
SKU 31984 - Model QSFP-40G-A1
1m (3ft) 40G QSFP+ Active Optical Cable for Cisco
40G AOC uses fiber optic technology for data transmission, which can replace copper cables to some extent due to its stability and flexibility, reducing the density and power consumption of cabling. It can also be used for data center and high performance computing network cabling.
BrandSUNFULL
Compatible brand / platformCisco
Length1m (3ft)
Use this selection as the requested coding target. Final compatibility still requires the host model, port type and firmware version.
Product brand: SUNFULL. Third-party names identify requested compatibility or coding targets only and do not imply affiliation, endorsement or original-equipment status.
- Minimum Bend Radius 7.5mm.
- Compliant with Hot Pluggable QSFP+ MSA Standard.
- Compliant with RoHS Environmental Standard (Lead-free).
- DDM(Digital Diagnostic Monitoring) Supported.
Engineering record
Specifications
Family-level values from the collected technical record. Confirm the selected SKU and required evidence in the quotation.
- Form Factor
- QSFP+
- Cable Length
- 1–30m (SKU-dependent)
- Commercial Temperature Range
- 0 to 70°C (32 to 158°F)
- Wavelength
- 850nm
- Jacket Material
- LSZH
- Power Consumption
- ≤1.5W
- Minimum Bend Radius
- 30mm
- Application
- 40G Ethernet Compliant
Technical detail
Construction and application notes for QSFP-40G-A1
Review connector, construction, routing and handling details that apply to the selected family and exact SKU.
Cable construction
AOC uses fiber optic technology for data transmission, which can replace copper cables to some extent due to its stability and flexibility, reducing the density and power consumption of cabling. It can also be used for data center and high performance computing network cabling. AOC can be compatible with more than ten kinds of mainstream compatible brands such as Cisco, Huawei, etc., and also provides humanized customization services that can meet different needs.
Routing and bend requirements
has a full range of professional test equipment for testing various parameters of products to ensure high performance and quality of optical transmission stability.
