MPO Female to Female 4x8F to 4x8F Type 4 Fiber Cable | M4MPOA32F4
Catalog reference: 10m (33ft) Pre-terminated MPO 4x4 Shuffle Trunk Cable, 32 Fibers, 4xMPO-8 APC (Female) to 4xMPO-8 APC (Female), Multimode (OM4), Type 4, LSZH, 0.35dB Max, Breakout 80cm, Magenta
Use the model and SKU to confirm the exact connector, construction, route and acceptance evidence for this passive component.
MPO 4x4 Shuffle Trunk Cable features 32 fibers with 4×MPO-8 APC female to 4×MPO-8 APC female connectors. It offers a factory-pre-terminated, plug-and-play alternative to field termination, eliminating on-site termination work, improving link reliability, lowering deployment complexity and cable footprint, and optimizing airflow management. It is ideal for interconnections between 400G QSFP-DD SR4 / 800G OSFP SR8 and 12-fiber backbone systems, enabling efficient physical layer conversion and speeding up GPU cluster deployment.
Family m4mpoa32f4-104745Model M4MPOA32F444 SKU options
Select the exact SKU
Search and select a SKU to update the exact title, description, model and option attributes before sending an RFQ.
SKU 104748 - Model M4MPOA32F4
10m (33ft) 4xMPO-8 APC Female to 4xMPO-8 APC Female OM4 Multimode Shuffle Trunk Cable (32 Fibers, LSZH, Type 4）
MPO 4x4 Shuffle Trunk Cable features 32 fibers with 4×MPO-8 APC female to 4×MPO-8 APC female connectors. It offers a factory-pre-terminated, plug-and-play alternative to field termination, eliminating on-site termination work, improving link reliability, lowering deployment complexity and cable footprint, and optimizing airflow management. It is ideal for interconnections between 400G QSFP-DD SR4 / 800G OSFP SR8 and 12-fiber backbone systems, enabling efficient physical layer conversion and speeding up GPU cluster deployment.
BrandSUNFULL
Cable Jacket/Flame RatingLSZH
Length10m (33ft)
Confirm passive fiber construction
- Connector Type
- MPO Female to Female
- Fiber Count
- 4x8F to 4x8F
- Polarity
- Type 4
Match connector type, fiber count, fiber type, polarity, keying, route length and insertion-loss budget before RFQ. Host-brand EEPROM coding does not apply.
- Multi-core, high-density design reduces cable count and saves routing space
- On-site "plug and play", fast installation, improve deployment efficiency
- Ultra-low insertion loss and high return loss ensure link consistency
- LSZH sheath, ensure safe indoor deployment and OFNP Fire Safety-Rated for use in Plenum Air Spaces
- Preorganized Shuffle Assemblies reduce installation time, streamlining deployment in large-scale GPU clusters
Engineering record
Specifications
Family-level values from the collected technical record. Confirm the selected SKU and required evidence in the quotation.
- Connector Type
- MPO Female to Female
- Fiber Grade
- Bend Insensitive
- Polish Type
- APC to APC
- Polarity
- Type 4
- Fiber Mode
- OM4 50/125μm
- Fiber Count
- 4x8F to 4x8F
- Wavelength
- 850/1300nm
- Cable Jacket/Flame Rating
- LSZH / OFNP (SKU-dependent)
- Insertion Loss
- ≤0.35dB
- Return Loss
- ≥35dB
- Attenuation at 850 nm
- ≤2.3 dB/km
- Attenuation at 1310 nm
- ≤1.0dB/km
- Cable Outside Diameter (OD)
- 3.5mm
- Min. Bend Radius
- 7.5mm
- Breakout Length
- 0.8m
- Breakout Outside Diameter (OD)
- 3.0mm
- Connector Durability
- ≥ 500 - 1000 times
- Tensile Strength
- 200/660N (Long/Short Term)
- Cable Structure
- Single Jacket
- Operating Temperature
- LSZH: -20~70°C OFNP: 0~70°C
