O2Q56-400G-CU2H | 400G OSFP 0.5–3m DAC
400G OSFP 0.5–3m DAC with 6 exact SKU options. Confirm the host, port and firmware before quotation.
InfiniBand Interconnects
400G OSFP 0.5–3m DAC | O2Q56-400G-CU2FH
Catalog reference: 2m (7ft) NVIDIA/Mellanox Compatible 400G DAC OSFP RHS/Flat Top 8x50G PAM4 to 2x200G QSFP56 4x50G PAM4 InfiniBand HDR Passive Direct Attach Copper Splitter Cable
The part numbers on this page identify the requested coding target. Confirm the exact host model, port and firmware for the selected SKU.
2m O2Q56-400G-CU2FH 400G OSFP(FLT) to 2X200G QSFP56 copper cable providing eight data transmission channels at speeds up to 56Gbps(PAM4) per channel, and meets 2X200G Ethernet and InfiniBand High Data Rate(HDR) requirements.
Family o2q56-400g-cu2fh-102386Model O2Q56-400G-CU2FH5 SKU options
Select the exact SKU
Search and select a SKU to update the exact title, description, model and option attributes before sending an RFQ.
SKU 102534 - Model O2Q56-400G-CU2FH
2m InfiniBand NDR DAC Splitter Cable 400G(Flat Top) to 2x200G(Flat Top)
2m O2Q56-400G-CU2FH 400G OSFP(FLT) to 2X200G QSFP56 copper cable providing eight data transmission channels at speeds up to 56Gbps(PAM4) per channel, and meets 2X200G Ethernet and InfiniBand High Data Rate(HDR) requirements.
BrandSUNFULL
Compatible brand / platformInfiniBand platform (vendor not specified)
Length2m (7ft)
Use this selection as the requested coding target. Final compatibility still requires the host model, port type and firmware version.
Product brand: SUNFULL. Third-party names identify requested compatibility or coding targets only and do not imply affiliation, endorsement or original-equipment status.
- Complies with OSFP MSA, CMIS 5.0, and RoHS protocols, providing a reliable and sustainable solution.
Engineering record
Specifications
Family-level values from the collected technical record. Confirm the selected SKU and required evidence in the quotation.
- Form Factor
- OSFP Flat Top to 2xQSFP56
- Cable Length
- 0.5–3m (SKU-dependent)
- Wire AWG
- 26AWG~28AWG
- Commercial Temperature Range
- 0~70°C(32 to 158°F)
- Jacket Material
- LSZH
- Power Consumption
- <0.1W
- Minimum Bend Radius
- 10x OD
- Application
- IB HDR, 200G/400G Ethernet Compliant
