Arista | QDD-400G-ZR | Transceiver
400G QSFP-DD Transceiver with 6 exact SKU options. Confirm the host, port and firmware before quotation.
RoCE Ethernet Interconnects
400G QSFP-DD VR4 50m Transceiver | QDD-400G-VR4 / QDD-400G-VSR4
Catalog reference: Arista Coding Target QDD-400G-VSR4 Compatible 400GBASE-VR4 QSFP-DD 8x50G PAM4 Broadcom DSP & Broadcom VCSEL 850nm 50m MMF DOM MPO-12/APC Optical Transceiver Module
The part numbers on this page identify the requested coding target. Confirm the exact host model, port and firmware for the selected SKU.
Arista Coding Target QDD-400G-VSR4 Compatible 850nm 50m MMF 400G Ethernet QSFP-DD VR4 transceiver module. It is an ideal solution for deploying 400G RoCE networking.
Family qdd-400g-vr4-103084Model QDD-400G-VR45 SKU options
Requested part-number references
- Requested coding target
- Arista
- Primary reference identifier
- QDD-400G-VSR4
Part-number identifiers and aliases available for matching:
- QDD-400G-VSR4
Review boundary: These identifiers reproduce source catalog matching terms only; they do not establish interoperability, approval or endorsement. Confirm the exact host model, port type, firmware and test evidence before use.
Select the exact SKU
Search and select a SKU to update the exact title, description, model and option attributes before sending an RFQ.
SKU 103084 - Model QDD-400G-VR4
Arista Coding Target QDD-400G-VSR4 Compatible Broadcom DSP & Broadcom VCSEL 400GBASE-VR4 QSFP-DD 850nm 50m Ethernet Optical Transceiver
Arista Coding Target QDD-400G-VSR4 Compatible 850nm 50m MMF 400G Ethernet QSFP-DD VR4 transceiver module. It is an ideal solution for deploying 400G RoCE networking.
BrandSUNFULL
Compatible brand / platformArista
Chip SolutionsBroadcom DSP & Broadcom VCSEL
Use this selection as the requested coding target. Final compatibility still requires the host model, port type and firmware version.
Product brand: SUNFULL. Third-party names identify requested compatibility or coding targets only and do not imply affiliation, endorsement or original-equipment status.
- Built-in Broadcom DSP & Broadcom VCSEL, Max Power Consumption ≤8W.
- Compliant with Hot Pluggable QSFP-DD MSA, IEEE 802.3bs, SFF-8679 Standard.
- Class1/1M Standard Product, Compliant with RoHS Environmental Protection Standards (Lead-Free).
- DDM (Digital Diagnostic Monitoring) Supported.
- Significantly Improve the Flexibility, Economy and Reliability of Networking.
Engineering record
Specifications
Family-level values from the collected technical record. Confirm the selected SKU and required evidence in the quotation.
- Form Factor
- QSFP-DD
- Distance
- 50m
- Wavelength
- 850nm
- Connector
- MTP/MPO-12 APC
- Power Consumption
- ≤8W
- Transmitter
- VCSEL
- Receiver
- PIN
- Media
- MMF
- Modulation (electrical )
- 8x53.125Gb/s PAM4
- Modulation (Optical )
- 4x106.25Gb/s PAM4
- Case Temperature(℃)
- 0 to 70°C (32 to 158°F)
- Protocol
- 400G Ethernet Compliant
Downloads
Technical documents
Use documents together with the exact SKU selection; document version and commercial validity should be reconfirmed during RFQ review.
