25G SFP28 40km Transceiver | SFP-25G-ER
Catalog reference: Cisco Coding Target SFP-25G-ER40-S Compatible 25GBASE-ER SFP28 1310nm 40km SMF DOM LC Duplex Optical Transceiver Module
The part numbers on this page identify the requested coding target. Confirm the exact host model, port and firmware for the selected SKU.
SFP-25G-ER SFP28 optical module offers optimal input/output (I/O) performance and 2.5 times the fiber capacity of 10G Ethernet performance. The biggest advantage that 25G Ethernet technology brings to the data center is the ability to maximize bandwidth and port density, saving operational costs by reducing the number of ToR switches and cables to provide the most energy efficient way to meet the growing demands of next-generation data center networks.
Family sfp-25g-er-14122Model SFP-25G-ER5 SKU options
Select the exact SKU
Search and select a SKU to update the exact title, description, model and option attributes before sending an RFQ.
SKU 31319 - Model SFP-25G-ER
25GBASE-ER SFP28 1310nm 40km SMF Module for Cisco
SFP-25G-ER SFP28 optical module offers optimal input/output (I/O) performance and 2.5 times the fiber capacity of 10G Ethernet performance. The biggest advantage that 25G Ethernet technology brings to the data center is the ability to maximize bandwidth and port density, saving operational costs by reducing the number of ToR switches and cables to provide the most energy efficient way to meet the growing demands of next-generation data center networks.
BrandSUNFULL
Compatible brand / platformCisco
Use this selection as the requested coding target. Final compatibility still requires the host model, port type and firmware version.
Product brand: SUNFULL. Third-party names identify requested compatibility or coding targets only and do not imply affiliation, endorsement or original-equipment status.
- Max Power Consumption ≤1.75W.
- Compliant with Hot Pluggable SFP28 MSA Standard.
- Class1/1M Standard Product, Compliant with RoHS Environmental Protection Standards (Lead-Free).
- DDM(Digital Diagnostic Monitoring) Supported.
Engineering record
Specifications
Family-level values from the collected technical record. Confirm the selected SKU and required evidence in the quotation.
- Product Type
- SFP-25G-ER
- Form Factor
- SFP28
- Max Data Rate
- 25.78Gbps
- Wavelength
- 1310nm
- Transmission Distance
- 40km
- Connector
- Duplex LC
- Media
- SMF
- Transmitter Type
- DFB
- Receiver Type
- APD
- TX Power
- 3~6dBm
- Receiver Sensitivity
- < -14dBm
- Typical Power Consumption
- ≤1.75W
- Commercial Temperature Range
- 0~70°C
- DDM
- Supported
- EMC ( Electro Magnetic Compatibility)
- Supported
- Modulation Mode
- NRZ
- CDR
- TX & RX Built-in CDR
- Protocols
- SFF-8472, SFF-8431, SFF-8432, SFP28 MSA, CPRI, eCPRI
- Compatible
- Cisco, Arista, Juniper, Dell, Mellanox, Generic
Technical detail
Construction and application notes for SFP-25G-ER
Review connector, construction, routing and handling details that apply to the selected family and exact SKU.
Optical interface and construction
25G WDM SFP28 optical module offers optimal input/output (I/O) performance and 2.5 times the fiber capacity of 10G Ethernet performance. The biggest advantage that 25G Ethernet technology brings to the data center is the ability to maximize bandwidth and port density, saving operational costs by reducing the number of ToR switches and cables to provide the most energy efficient way to meet the growing demands of next-generation data center networks.
Link application
has a full range of professional test equipment for testing various parameters of products to ensure high performance and quality of optical transmission stability.
Handling and validation
Handling and validation
