NVIDIA/Mellanox | OSFP-400G-2xSR4H | Transceiver
400G OSFP 2xSR4H 30m (OM3) /50m (OM4) Transceiver with 1 exact SKU option. Confirm the host, port and firmware before quotation.
InfiniBand Interconnects
400G OSFP SR4H 30m (OM3) /50m (OM4) Transceiver | OSFP-400G-SR4H / 980-9I51S-00NS00
Catalog reference: NVIDIA/Mellanox Coding Target MMA4Z00-NS400 (980-9I51S-00NS00) Compatible 400G SR4 OSFP RHS/Flat Top 4x100G PAM4 Broadcom DSP & Broadcom VCSEL 850nm 50m MMF DOM MPO-12/APC InfiniBand NDR Optical Transceiver Module
The part numbers on this page identify the requested coding target. Confirm the exact host model, port and firmware for the selected SKU.
NVIDIA Coding Target MMA4Z00-NS400 (980-9I51S-00NS00) compatible OSFP 400G SR4 MMF module, ensuring stable 400G InfiniBand NDR and Ethernet transmission up to 50m.
Family osfp-400g-sr4h-101490Model OSFP-400G-SR4H2 SKU options
Requested part-number references
- Requested coding target
- NVIDIA/Mellanox
- Primary reference identifier
- 980-9I51S-00NS00
Part-number identifiers and aliases available for matching:
- 980-9I51S-00NS00
- MMA4Z00-NS400
Review boundary: These identifiers reproduce source catalog matching terms only; they do not establish interoperability, approval or endorsement. Confirm the exact host model, port type, firmware and test evidence before use.
Select the exact SKU
Search and select a SKU to update the exact title, description, model and option attributes before sending an RFQ.
SKU 101490 - Model OSFP-400G-SR4H
NVIDIA/Mellanox Coding Target MMA4Z00-NS400 400G OSFP SR4 InfiniBand NDR Transceiver with Broadcom DSP & VCSEL
NVIDIA Coding Target MMA4Z00-NS400 (980-9I51S-00NS00) compatible OSFP 400G SR4 MMF module, ensuring stable 400G InfiniBand NDR and Ethernet transmission up to 50m.
BrandSUNFULL
Compatible brand / platformInfiniBand platform (vendor not specified)
Chip SolutionsBroadcom DSP & Broadcom VCSEL
Use this selection as the requested coding target. Final compatibility still requires the host model, port type and firmware version.
Product brand: SUNFULL. Third-party names identify requested compatibility or coding targets only and do not imply affiliation, endorsement or original-equipment status.
- Complies with OSFP MSA, CMIS 4.0, and RoHS protocols, providing a reliable and sustainable solution.
Engineering record
Specifications
Family-level values from the collected technical record. Confirm the selected SKU and required evidence in the quotation.
- Chip Solutions
- Broadcom DSP & Broadcom VCSEL / Coherent VCSEL & Broadcom DSP (SKU-dependent)
- Form Factor
- OSFP
- Distance
- 30m (OM3) /50m (OM4)
- Wavelength
- 850nm
- Connector
- MPO-12/APC
- Power Consumption
- ≤9W
- Transmitter
- VCSEL
- Receiver
- PIN
- Media
- MMF
- Modulation (electrical)
- 4x106.25Gb/s PAM4
- Modulation (Optical )
- 4x106.25Gb/s PAM4
- Case Temperature(℃)
- 0~70°C(32 to 158°F)
- Protocol
- IB NDR,400G Ethernet Compliant
