980-9I302-00NM00 | OSFP-800G-2DR4F | Transceiver
800G Twin-port OSFP 2xDR4 500m Transceiver with 1 exact SKU option. Confirm the host, port and firmware before quotation.
RoCE Ethernet Interconnects
800G Twin-port OSFP 2xDR4S 100m Transceiver | OSFP-800G-2xDR4S / 980-9I30H-F4NM00
Catalog reference: NVIDIA/Mellanox Coding Target MMS4X00-NS-T (980-9I30H-F4NM00) Compatible 800GBASE-2xDR4 OSFP IHS/Closed Finned Top 8x100G PAM4 1310nm 100m SMF DOM Dual MPO-12/APC Optical Transceiver Module for SN5610 Series Switch
The part numbers on this page identify the requested coding target. Confirm the exact host model, port and firmware for the selected SKU.
NVIDIA/Mellanox Coding Target MMS4X00-NS-T Compatible 800G 2xDR4/DR8 OSFP Finned Top PAM4 1310nm optical transceiver modules.
Family osfp-800g-2xdr4s-103203Model OSFP-800G-2xDR4S2 SKU options
Requested part-number references
- Requested coding target
- NVIDIA/Mellanox
- Primary reference identifier
- 980-9I30H-F4NM00
Part-number identifiers and aliases available for matching:
- 980-9I30H-F4NM00
- MMS4X00-NS-T
Review boundary: These identifiers reproduce source catalog matching terms only; they do not establish interoperability, approval or endorsement. Confirm the exact host model, port type, firmware and test evidence before use.
Select the exact SKU
Search and select a SKU to update the exact title, description, model and option attributes before sending an RFQ.
SKU 103203 - Model OSFP-800G-2xDR4S
NVIDIA/Mellanox Coding Target MMS4X00-NS-T (980-9I30H-F4NM00) Compatible 800G 2xDR4/DR8 PAM4 1310nm 100m Optical Transceiver for SN5610 Series Switch
NVIDIA/Mellanox Coding Target MMS4X00-NS-T Compatible 800G 2xDR4/DR8 OSFP Finned Top PAM4 1310nm optical transceiver modules.
BrandSUNFULL
Compatible brand / platformNVIDIA/Mellanox (Ethernet)
Use this selection as the requested coding target. Final compatibility still requires the host model, port type and firmware version.
Product brand: SUNFULL. Third-party names identify requested compatibility or coding targets only and do not imply affiliation, endorsement or original-equipment status.
- Max Power Consumption ≤16W.
- Compliant with Hot Pluggable OSFP MSA, IEEE802.3ck Standard.
- Class1/1M Standard Product, Compliant with RoHS Environmental Protection Standards (Lead-Free).
- DDM (Digital Diagnostic Monitoring) is supported.
Engineering record
Specifications
Family-level values from the collected technical record. Confirm the selected SKU and required evidence in the quotation.
- Form Factor
- Twin-port OSFP
- Distance
- 100m
- Wavelength
- 1310nm
- Connector
- Dual MTP/MPO-12 APC
- Power Consumption
- ≤16W
- Transmitter
- EML
- Receiver
- PIN
- Media
- SMF
- Modulation (electrical)
- 8x106.25Gb/s PAM4
- Modulation (Optical)
- Two ports 4x106.25Gb/s PAM4
- Case Temperature (℃)
- 0 to 70°C (32 to 158°F)
- Protocol
- 800G Ethernet Compliant
Downloads
Technical documents
Use documents together with the exact SKU selection; document version and commercial validity should be reconfirmed during RFQ review.
