NVIDIA/Mellanox Coding Target MMA4Z00-NS400-T (980-9I51S-F4NS00) Compatible Broadcom DSP & Broadcom VCSEL OSFP-400G-VR4...

RoCE Ethernet Interconnects

400G OSFP VR4 50m Transceiver | OSFP-400G-VR4 / 980-9I51S-F4NS00

Catalog reference: NVIDIA/Mellanox Coding Target MMA4Z00-NS400-T (980-9I51S-F4NS00) Compatible 400GBASE-VR4 OSFP RHS/Flat Top 4x100G PAM4 Broadcom DSP & Broadcom VCSEL 850nm 50m MMF DOM MPO-12/APC Optical Transceiver Module

The part numbers on this page identify the requested coding target. Confirm the exact host model, port and firmware for the selected SKU.

Technical product family for NVIDIA/Mellanox Coding Target MMA4Z00-NS400-T (980-9I51S-F4NS00) Compatible Broadcom DSP & Broadcom VCSEL OSFP-400G-VR4 PAM4 850nm 50m Optical Transceiver. Review the specifications and exact SKU options below.

Family osfp-400g-vr4-103080Model OSFP-400G-VR44 SKU options

Requested part-number references

Requested coding target
NVIDIA/Mellanox
Primary reference identifier
980-9I51S-F4NS00

Part-number identifiers and aliases available for matching:

  • 980-9I51S-F4NS00
  • MMA4Z00-NS400-T

Review boundary: These identifiers reproduce source catalog matching terms only; they do not establish interoperability, approval or endorsement. Confirm the exact host model, port type, firmware and test evidence before use.

Select the exact SKU

Search and select a SKU to update the exact title, description, model and option attributes before sending an RFQ.

SKU 103080 - Model OSFP-400G-VR4

NVIDIA/Mellanox Coding Target MMA4Z00-NS400-T (980-9I51S-F4NS00) Compatible Broadcom DSP & Broadcom VCSEL OSFP-400G-VR4 PAM4 850nm 50m Optical Transceiver

Technical product family for NVIDIA/Mellanox Coding Target MMA4Z00-NS400-T (980-9I51S-F4NS00) Compatible Broadcom DSP & Broadcom VCSEL OSFP-400G-VR4 PAM4 850nm 50m Optical Transceiver. Review the specifications and exact SKU options below.

BrandSUNFULL
Compatible brand / platformNVIDIA/Mellanox (Ethernet)
Chip SolutionsBroadcom DSP & Broadcom VCSEL

Use this selection as the requested coding target. Final compatibility still requires the host model, port type and firmware version.

Product brand: SUNFULL. Third-party names identify requested compatibility or coding targets only and do not imply affiliation, endorsement or original-equipment status.

Get Datasheet & Quote Compatibility Review WhatsApp Technical Documents
Share: LinkedIn Facebook X Email
  • Built-in Broadcom DSP & Broadcom VCSEL, Maximum Power Consumption ≤9W.
  • Compliant with Hot Pluggable OSFP MSA, IEEE 802.3ck, CMIS 4.0 Standard.
  • Class1/1M Standard Product, Compliant with RoHS Environmental Protection Standards (Lead-Free).
  • DDM(Digital Diagnostic Monitoring) Supported.
  • Significantly Improve the Flexibility, Economy and Reliability of Networking.

Engineering record

Specifications

Family-level values from the collected technical record. Confirm the selected SKU and required evidence in the quotation.

Form Factor
OSFP
Distance
50m
Wavelength
850nm
Connector
MTP/MPO-12 APC
Power Consumption
≤9W
Transmitter
VCSEL
Receiver
PIN
Media
MMF
Modulation (electrical)
4x106.25Gb/s PAM4
Modulation (Optical )
4x106.25Gb/s PAM4
Case Temperature(℃)
0~70°C (32 to 158°F)
Protocol
400G Ethernet Compliant
